Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 241
Fig. 767.—Conventional Detail at Head of Post. Fig. 769.—View of Straining Piece and Strutbutting against it. … n £. 1 ¥ Boarding Fig. 766.—Section through Gantry. Another Gantry. Figs. 764 to 766 are illustrations of a gantryfor use over a pavement 8 ft. wide and withstaging 12 ft. from the ground, A conventional sketch of the gantry is given atFig. 764, and views of the necessarv jointsby Figs. 767 to 769.
Carpentry · Joinery
