Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 288
Fig. 870.—Conventional View of Centrefor converging Jambs (Fig. 868). … 871.—General View of Inner Centresfor Parallel Reveals (Fig. 868). Fig. 869. soffit with the converging reveals ; but thecareful reader will have little difficulty if henote that this case is a combination of thetwo previous ones (Figs. 859 to 867), which Fig. 868.—Elevation of Centering for an…
Carpentry · Joinery
