Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 29
Fig. 62.—Smoothing Plane. of the tool, thus enabling the angles ofrebates to be cleaned up. Other varietiesof planes include the bead plane (Figs. 66to 68), used for working single and returnbeads and round rods. Hollows, rounds,etc. (Figs. 69 to 73), are used for working is made of steel entirely.… … Fig. 64.—Iron Smoothing Plane. and yV m- thick. It is adjusted by meansof a screw, and with it both concave andconvex surfaces may be worked perfectly
Carpentry · Joinery
