ls of Joints at(Fig. 891). and G All the parts of each principal were con-nected together by f-in. bolts and nuts withwashers, and straps at the foot of the king-post. Packing pieces were used wherenecessary, as indicated at a (Fig. 894) andb (Fig. 897). The principals were bracedat 6-ft. centres… … -Detail of Foot ot King-post,(Fig. 891).
