Fig. 1176. -Setting Out of Shoulders on BackSide of Stiles. down the edge, the point d is found, andjoining d to a, the inside shoulder is shown.Now squaring across from h as shown bythe second dotted line, the point k is ob-tained ; from the arris measuring the thick-ness of the bead, the point f… … Fig. 1177.—Application of Adjustable Squarefor Setting Out Shoulders on Stiles. o. Thus point f is obtained, and joiningF to b gives the shoulder line. On the in-side of the stile (Fig. 1176) square acrossfrom the line L, and where this intersects
