Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 388
other examples, andwhich have been already treated, will-notbe recapitulated ; only the principal new DOORS AND DOOR FRAMES. 359 features will be explained and illus-trated. Frame.—A portion of the rod with thehead set out is shown at Fig. 1187 ; pro-jected above this, the top end of the post is… … Fig. 1188. Setting Out for Mortices in Head ofFrame. Fig. 11S0.—Showirg Grooved and Tougued Jointbetween Jamb and Soffit of Linings.
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
