Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 422
circular in elevation,and stilted 4 in. The outerarris of the soffit of the archis taken as a semicircle (seeab, Fig. 1273). The revealsradiate, and therefore the soffitat the springing on each sidealso radiates, but it finisheslevel at the crown as shown atc. Thus the arris of the soffitof the… … Fig. 1276.—Enlarged Vertical Section throughHead, Transom, and Centre of Upper Panels.
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
