Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 431
Fig. 1299.—Enlarged Section of Transom forCircle-on-Circle Door Frame. mentioned, double tenons are used for thetransom ; this is to avoid cutting the fibresat the root of the key, and the insides of themortices should come in line with the outsidelines of the key, and in thickness they shouldbe TV… … Fig. 1300. -Enlarged Section of Head at Crown ofCircle-on-Circle Door Frame. and Fig. 1300 a section of head at crown.Having set the sight lines of the jambs on theface edge of the transom, measure out and :pencil lines representing the thickness of DOORS AND DOOR FRAMES. 401 jamb, prick the…
Carpentry · Joinery
