Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 434
Fig. 1307. -Enlarged Section through Bottom Panel of Circle-on-Circle Swing Doors on Line E E (Fig. 1301). fitted to the cylinder, the proper curve willbe obtained by using a trammel with arising and falling slide at the striking point, Fig. 1309 H<. … Figs. 1308 and 1309.—Method of Setting OutFanlight of Circle-on-Circle Swing Doors. similar to Fig. 1295, the head, etc., beingreversed. The bars in the fanlight, as well with a deal core and hardwood facings.The narrow frieze being prepared from j-in.material, it may be bent round the sweep.The…
Carpentry · Joinery
