Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 440
shown by Fig. 1314. WINDOW SASHES AND CASEMENTS. Setting Out Sash Frame Head.—To set out the head, place the sill on it and mark the face lines of the pulley stile, as a and b (Fig. 1324) ; square over the face, and gauge for the housing f in., which may be made tongues should be cut off at each… … Fig. 1328. Second Stage of Setting Out PulleyStiles.
Carpentry · Joinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
