Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 520
of nearly equal thickness,and as the lower one projects this necessi-tates preparing and fixing blocks as shownat A; these fit to the back of the skirting.The grounds c are as previously described.Where the skirtings meet at the internalangles, they are usually grooved, tongued,and scribed, as… … Fig. 1602.—Lead Plug. Fig. 1603.—Cast-IronBox for Gas Bracket. nailing is not permissible, secret dovetailinggives the best result. This is illustrated atFig. 1601, which shows the mitre and socketscut to receive the other pieces. Lead Plugs and Iron=cased Plugs. All plugs and woodwork should be…
Carpentry · Joinery
