Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 549
und M having beenscrewed to the dado moulding at n, theseare placed in position with the tongueof the ground fitting into the top of thedado as shown. The ground m is thenfixed to the wall ground G by nailing throughthe rebate as shown at R. The dado mouldand the ground R have a groove formed… … Fig. 1676.—Method of Fixing Cornice to the Topof the Framing. projecting above the ground g, forms arebate at the back, allowing the bottomends of the blocks f to fit into the rebate.These blocks are secured to the back ofthe mouldings forming the cornice, andthen the top ends of the blocks are…
Carpentry · Joinery
