Hasluck, Paul N. (Paul Nooncree), 1854-1931, ed · Philadelphia, D. McKay · leaf 73
mp;iad 188), andTredgold notching (Fig. 189). Cogging isshown by Fig. 190, the birds-mouthed jointby Fig. 191, the bridle joint by Figs. 192and 193, and dowelling of wood to stone byFig. 191. Tenon Joints (Carpenters).—Of tenonjoints there is the stump, or stub tenon (Fig.195); the shouldered tenon… … Fig. 199.—Section of Tusk Tenon Joint
Carpentry · Joinery
