Thisroad would be useful in opening up many improvements connected witli therising town of Tramore, the Brighton of the South of Ireland. Fig. 1.—Plan of Harbour. 1 j . Ifcsii - mm V i mill mm =cd=c r i It -r-r-rx: 100 150 Scale of Feet. 200 350 References. A A A, Low-water spring tides B B B,… … References.A A, High-water spring-tides.—B B, Low-water spring fides.—C, Top ofquay, 18 feet wide.—D, Parapet at top of storm pavement.—E E, Break-water glacis, or storm pavement. 1 have in Fig. 1 delineated a second arm or pier to the proposed safetyharbour; bul as the execution of this part would…
