The Civil engineer and architect's journal, scientific and railway gazette (1839)
London : [William Laxton] · leaf 182
FiK. 4. Fig. 5. … I-ig. 6.p-iSl -f Scale of enlarged parts figs. 3, 4. 3, 6—quarter inch equal to a foot. same dimensions. The buckets, of which there are 280, are 9 in.wide at the top, 5 in. at the bottom, 15 in. in breadth, and 10^ in.deep. The shaft A is of cast iron hollow, 14 ft. y in. long betweenthe bearings,…
