tangents on the pitch, and which, when placed in posi-tion, would stand plumb over ABC. i8 COMMON-SENSE HANDRAILING 7ari0tnt … To construct Fig, 13, proceed in the same manner asin Fig. 12, until the height is located. It will be noticed that in this exam-ple BG is lifted higher,making the pitch-lines andtangents FG and DG of un-equal lengths. To obtainthe angle continue BG toH, making BH equal toEF; from H draw the lineHJ…
