Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .. (1880)

Warren, S. Edward (Samuel Edward), 1831-1909 · New York, J. Wiley & sons · leaf 118

An illustration from Elementary projection drawing. Theory and practice. For preparatory and higher scientific schools, industrial and normal classes; and the self-instruction of teachers, inventors, draftsmen, and artisans. In six divisions .., 1880, leaf 118
at no more thanthe cost of riveting. This question appearsto have exercised other minds, and Fig. 14indicates one solution of it,* consisting ofcylindrical segments bearing dovetailed inplace of rectangular flanges on their edges,and. united by clamping bars in place of riv-ets ; as one would hold… … * Manufactured by Carnegie Brothers & Co., Pittsburg, Pa. DIVISION THIED. ELEMENTARY SHADOWS AND SHADING. CHAPTER I. SHADOWS. § I. —Facts, Principles, and Preliminary Problems. 158. The shadow of a given opaque body, B, PL IX., Fig.78, upon any suriace S, is the portion of S from which light…

Geometrical drawing · Mechanical drawing
