THIRD METHOD … ,10. Fig. 2], 18 Fig. 22 is the stretchout ordevelopment of the tangentlines. To draw this let theline LM be the edge of thedrawing board; with a bevelset to a convenient angle theend of the winder and riserwould give the pitch. Drawthe line BB; then parallelwith BB draw AA at adistance equal to…
