The complete motorist, being an account of the evolution and construction of the modern motor-car; with notes on the selection, use, and maintenance of the same; and on the pleasures of travel upon the public roads (1905)

Young, Filson, 1876-1938 · New York : McClure, Phillips & co.; London, Methuen & co. · leaf 135

An illustration from The complete motorist, being an account of the evolution and construction of the modern motor-car; with notes on the selection, use, and maintenance of the same; and on the pleasures of travel upon the public roads, 1905, leaf 135
60-H.p. mp:rcede.s engine, right-hand side A—FLOAT-FEED CHAMBER Al—SPRAY CHAMBER A2—THROTTLE VALVE A4—CYLINDER-HEAD CASTINGS A3—BRANCH FEED FIFE A5—ROD FROM C;oVEKNOR REGULAIINO IHROTTLE B—VALVE SPINDLES Bl—HORIZONTAL ROCKING LEVERS OPEN AUNG INLET VALVE;. B2—PARAFFIN COCKS E—LOW TENSION IGNITERS…

Automobiles

Internet Archive · California Digital Library · Public Domain Mark 1.0. Free to use for anything.
