SOME TYPES OF PETROL CAR 117 which again are quite different from those in any other system.The incHnation of the steering centres results in the absorptionof all road shocks (which tend to deflect the wheel) at the tyre,and thus relieves the steering connections from all compres- … PLAN AND ELEVATION OF DURYEA CHASSIS A- BB- C- DD- E FF- G- HH- II- JJ-K-L-M-N-O-P- Q- -Seat Frame. -Springs. -Brackets. -Head Lugs. -Axle. -Tubular Supports to Axle. -Steering Post. -Arms on Steering Post. -Steering Rods. -Steering Arms. -Steering Connections. -Tiller. -Seat Frame. -Engine. -Power…
