ude of 40 above the G.P. The working points, etc., for drawing these blocks andshadows were set out to a scale of V = 1, but as they cannot beshown in the space at our disposal, they are set out in a supple-mentary diagram drawn to a scale of yg = 1. SCIOGRAPHV OR THE PROJECTION OF SHADOWS 209 In… … produce it to meet li.l. in P. AVith P as centre, and its distancefrom s as radius, draw an arc to meet li.l. in a. Draw a line,making, at a, an angle of 40° with li.l., and produce it to meet avertical line drawn at P in L. Then L is the V.P. of the sunsrays, and PL the V.L. of the plane of shade.…
