iiT l|k^. — / Jffansteins Co7\f>tructive Drawing, 313.—Fig. 1.—Problem.—To consfract a tangent to an ellipsewhen the point of eontact is given. Solution.—liet A C B D be the ellipse and Q the point of con-tact. Describe from G as center, with.radius G F, the arc F N,and draw and produce line F…
