Constructive drawing. A text-book for home instruction, high schools, manual training schools, technical schools and universities (1904)
Hanstein, Herman. [from old catalog] · Chicago, New York [etc.] Keuffel & Esser co. · leaf 66
Fig 4. … Hansteins Cdnstnictive Drawing. GEAR LINES—CYCLOID. 131.—Fig. 1.—Problem—To construct a cycloidwhen the generating point A is given at the cir-cumference of the circle. Definition.—A cycloid is a curve generated by apoint at the circumference of a circle, making onerevolution in rolling on a…
Mechanical drawing
