Cyclopedia of textile work : a general reference library on cotton, woollen and worsted yarn manufacture, weaving, designing, chemistry and dyeing, finishing, knitting, and allied subjects (1907)
Chicago : American school of correspondence · leaf 274
Fig. 167. Fly Frame Bobbin. ?43 COTTON SPINNING 201 … 24S 202 COTTON SPINNING screw from the cone rack, I^, by the taper gear. At each end of thetraverse, the builder screw is turned a trifle and the jaws are broughtmore closely together. The builder and parts directly connected areshown on an enlarged scale in Fig. 170. When the bobbin rail is moving…
Textile industry · Textile fabrics
