immediately stop, otherwise there would be a thinstreak across the cloth. The filling stop motion, or fill-ing fork is designed for this purpose. FILLING STOP flOTION.—FIG. 41.—LETTERING. A Loose Pulley. B Tight Pulley. C Belt Shifter. D Guide for Belt Shifter. E Loom Handle (broken off at top.) F… … 224 FILLING STOP MOTION.— Fig. 41 shows position ofOperation. parts when loom is run- ning.Loom handle E is pulled over so that belt is on tightpulley. It is held in the notch in loom beam, otherwisethe spring S would shift belt on loose pulley. Cam P keeps bar O oscillating. As long as the…
