Blueprint reading; a practical manual of instruction in blueprint reading through the analysis of typical plates with reference to mechanical drawing conventions and methods, the laws of projection, etc (1919)
Fairfield, Howard Parker, 1858-, Kenison, Ervin, Waite, Edward B. (Edward Broughton), 1873-, American Technical Society · Chicago, American technical society · leaf 9
reasons why this is not possible, and it is with the idea of givingthe requisite amount of drafting knowledge and practice invisualizing the finished product from plans, elevations, and sec-tions that this little volume has been prepared. With a carefulstudy of the lessons herein .laid down will… … CONTENTS The page numbers of this volume will be found at the bottom of the pages;the numbers at the top refer only to the section. BLUEPRINT READING PAGE Introduction 11 Process of making blueprints h 11 What blueprints should show 12 General directions 13 Meaning of projection 15 Lines 16 Symbols…
