A course in mechanical drawing for evening schools and self-instruction (1896)
Rouillion, Louis · Boston, New York, The Prang educational company · leaf 79
xception. This sheet would be quiteas serviceable without the shade lines. It adds some-what of a finish to the drawing, but is here givensimply as an example, and to explain the method.The light is supposed to come from the upper left-hand corner of the sheet at an angle of 45°. There-fore, the… … / - Aaaembly£-Head StochJ- Too/ Heat•rf- 7ai/ ■Stocli.■S- Bed Bench UotheAssembly. a-a-se. L-2-1 72 COURSE IN MECHANICAL DRA WING. SHEET XXVI. Bench Lathe — Details of Head-Stock. The designing of a machine and the making of theoriginal drawings for it is not a subject to concern thestudent of…
Mechanical drawing
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
