, however, CII. V\ DRAWING WITH THE MICROSCOPE 153 the range must be still further increased. For a moderate increasein size the drawing surfaee may be put farther off or, as one morecommonly needs less rather than greater magnification, the drawingsurface may be brought nearer the mirror of the… … Fig. 133. Room and Apparatus for Drawing with the Projection Micro-scope. R. Radiant, an arc lamp with carbons at a right angle ; L. t. Lampand microscope table; C. Condenser with IV. a large water bath between thelenses to absorb the heat rays; S. w. Stage and stage water bath on whichrests the…
