which is split up into two byreflection and transmission at the surface is resolved into twobeams, one (A D) which is transmitted, the other (A B C) which THE MICROSCOPE STAND 109 is reflected, and the reflected light at the time it emerges hastravelled a path that is longer than the direct light… … Vi 1 Beck Fig. 102.- -Diagram showing paths of light through the Beck BinocularMicroscope. (A) Eyepiece. (B) Drawtube. (D) Body. (E) Coarse focussing adjustment.(V) Prism box knob. (9) Sliding prism box. (O) Object glass. CI) stage. (K) Substage condenser. (L) Iris diaphragm. (M) Substage focussing…
