the sliding-head 0, and, passing through thespur wheel D, is provided with the conical roller E, running freeupon its upper end. The spindle is embraced in the spur wheel Dby a sliding block, G, free to move in a slide formed in the wheel,and pulled off the centre outwards by a pair of strong… … GE OME TRIG A L PROPER TIES. «5i triangular, so likewise will the path described by the centre of theroller; if it be circular, so likewise will the path described by thecentre of the roller; and so on. The template F is secured to pro-jections, J, from the head by means of clips, K, so as to admit…
