e rack as it rolls outside the pitchcircle of the pinion. For contact to take place during recess, thepinion must drive the rack (Fig. 328). The parallel curve to an involuto ie itself an involute of the Bame base circle. TOOTHED CIRCULAR WHEELS. 295 § 184. Chain Wheels.—In chain wheels, such as…
