FiQ. 390. NON-CIRCULAR WHEELS. 355 … By means of templates rotating about P3, will keep in rolling contact with A and Bmust be obtained from either of these curves in exactly the samemanner as B is determined from A.When its shape has been determined,attach a pencil to any point D in it,and, as motion takes place, let Ddescribe two…
