Advanced theory of electricity and magnetism; A text-book for colleges and technical schools (1915)
Franklin, William S. (William Suddards), 1863-1930, MacNutt, Barry, 1878-1936. joint author · New York, Macmillan · leaf 248
supposed to be rotating at a speed of /revolutions per second in a counter-clockwise direction as seenfrom right hand end; and the projections of the arrows on theplane of the paper represent the instantaneous values of currentand voltage at the various points of a transmission line which… … reflected wave-train{lettered vectors) side view end view Fig. 173. Clock diagram model of two simple wave trains, one moving to the right and one moving to the left, The clock diagram model of Fig. 172 may be derived from Figs.169 and 170 by considering that a standing wave train is…
Electricity · Magnetism
