Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 149
nd y have no commonfactor, and the winding is therefore simply closed on itself, although elec-trically it is divided into four parallel paths. The brushes iriust be wideenough to cover more than one segment. In general, a winding-step of agives a winding with 2a parallel paths. In this way we are… … Fig. 119 parallel paths. It is easy to see that the series ring-winding previouslydescribed was merely a special case of the series-parallel winding, in which awas made equal to i. We shall confine ourselves to the more important Case in which thenumber of parallel paths is equal to the number of…
Electrical engineering
