Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 270
in increasing theapparent internal resistance of an alternating current generator. 78. Resistance and Inductance in Parallel. In the case illustrated in Fig. 250 two branches are connected in parallel,each containing both ohmic and inductive resistance. The terminal pres-sure V is exactly the same… … Fig. 250 and partly inductive, as shown in Fig. 250. We have now to determine themagnitude and phase of the total current, and the current in each branch,from a knowledge of V, Ri, wLi, i?2 ^^^ mL^. The line OG in Fig. 251 isdrawn to represent the terminal pressure V, and a semicircle is…
Electrical engineering
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
