could berepresented by accurate resistances of such values that the end connections would be quite negligible. Inthe ordinary form of bridge, however, it is impossible to eliminate the effectof the connection between x and R. If, in Fig. 14, the galvanometer beconnected to the end of x, R will be… … Fig. 15 i8 Electrical Engineering connecting the galvanometer through resistances iJ^ and R^ to both x and R(Fig. 15). The former direct connection between x and R, shown at thebottom of Fig. 15, still remains. We see that there are now two leads con-nected to each end of both x and R. The…
