lation.—loi. Effect of polar leakage. 96. The E.M.F. Diagram for an A.C. Generator. If the assumption be made that the coefficient of self-induction of thearmature of a machine has a constant value for all conditions of load andexcitation, the vector diagram is extremely simple. The… … Fig. 308 inductive pressure drop, both internal and external, while the other sideis equal to the sum of the internal and external ohmic pressure drops. Thedirection of the current vector in Fig. 307 is vertically upwards. The self-induction induces an e.m.f. lagging 90° behind the current, which…
