Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 373
rotated through 45° from the position they occupied in Fig. 362.On turning the generator through another 45°, the stator coils i and 3 willhave no current, while the current in coils 2 and 4 wUl have reached itsmaximum. There will then be a north pole at i and a south pole at 3. We have thus… … Generator Motor Fig- 363 therefore imagine the stator to be replaced by a rotating field-magnetsystem with salient poles pointing inwards. The flux of such a field-magnetwould continually cut through an iron cylinder placed within the statorring (compare Fig. 382). This iron cylinder is caUed the…
Electrical engineering
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
