Thomälen, Adolf, 1865-, Thomälen Adolf. Kurzes Lehrbuch der Electrotechnik. English · London, E. Arnold · leaf 408
r and rotor cores. The 122. Calculation of the Electromotive Force 393 flux per tooth will therefore be proportional to the ampere-turns acting onthe flux in that tooth, and may, so far as we are concerned with merelyrelative values, be put equal to the ampere-turns. If the maximum current be taken… … Fig. 399 The other slots carry only half the current, but the flux links all the gslots of our upper phase, so that we have (ft) ToothI IIIII Effective ampere-turns or flux in tooth Turnslinked Number oflinkages ^ fe + I) g{S + 2)g{g + 3) y 2g-i.2 g g{2g-l) The number of turns in this series is {g…
Electrical engineering
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
