are entirely distinct in the AT-diagram, stands witness to theobscurity of the evidence as to what is thermally transpiring in the cylinderwhich is offered by the indicator-card. 102 THE THERMODYNAMICS OF HEAT-ENGINES wet steam so deleterious, and will be explained in the Sec-ond Part of this work.… … Fig. ii Again, the point D (Figs. 11 and 12) represents the con-dition of the steam-heat as the supply from the boiler iscut off in the pump-cylinder. But now, instead of beingallowed to expand adiabatically, the heat is abstracted atconstant volume while the piston stands still at the end ofthe…
