cator-cards developed would bethe exact likeness of BCDE, Fig. 52, upon a diminished lon-gitudinal scale, and would develop a like efficiency; exceptthat now the terminal pressure EB has opportunity for fur-ther expansion during the remainder of the stroke, to theright of the new positions of E.… … JSo Brake Load. Engine Friction OnJyFIG. 57 to make the efficiency an increasing instead of a decreasingfunction of the load as the latter falls from maximum. The movement of B toward A under the influence of thegovernor as the load diminishes would result in the vari-ation of efficiency with load…
