fig. 169. The plunger P is forced inwards by a rooking levershown clearly in the general drawing. As the plungermoves forward it cuts ofi the oil inlet port through which THE GAEDNEE Oil. ENGINE. 335 … 336 THE GAEDNEE OIL ENGINE. oil enters the barrel of the pnmp by gravity from the supplytank. The oil charge is then forced past the foot valve anddelivered to an open cup on the vaporiser, whence it is
