A practical treatise on modern gas and oil engines (1902)
Grover, Frederick · Manchester, The Technical Publishing Co., Limited; [etc., etc.] · leaf 55
terminatesin a fork, -which when moved sideways (see fig. 27) engagesthe end of the bell-crank lever, overcomes the tension of the 44 TYPES OF GAS ENGINES. spiral spring, so that when the tripper blade rises it missesthe notch under A on the gas-valve spindle, thus cuttingout entirely the gas… … Fig. 28.—Stockport Gas Engine—Arrangement of Governor for Small Engines. by compressing the spring on the governor spindle bymeans of two adjusting lock nuts. The peculiar and sudden action of cam-driven leversrenders it possible to entirely cut out the gas supply, whenthe speed increases, by a…
Internal combustion engines
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
