Grieves, Loren C. (Loren Chester), b. 1878 · Washington, United States Infantry Association · leaf 71
Fia. 19 MiLiTAET Sketching die of one end of the block saw out a slit ^ wide and extend-ing an inch and a half into the block. By means of wire nailsdriven as shown in Fig, 21c, attach the three legs to the block. … Pig. so Flat Sketch 65 one leg in the slit and the remaining two legs at the other endof the block. Then drive a wire nail into the center of the bot-tom of the block; the nail being of sufficient length so thatit will protrude % out of the block. (See Fig. 21c.)When all of this has been completed,…
Maps, Military · Military topography
