Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 137
.BUTTERFLY T SECONDARY■WELL P -CHOKE X -CAP JET H MAIN JET C COMPENSATOR I Fig. 51.—Sectional View of Zenith Compound Nozzle Compensating Carburetor. 136 Aviation Engines … Action of Zenith Carburetor 137 inference to suppose that as the speed of the motor in-creases, both the flow of air and of gasoline will increasein the-same proportion. Unhappily, such is not the case.There is a law of liquid bodies which states that the flowof gasoline from the jet increases…
Airplanes
