Aviation engines; design--construction--operation and repair; (1919)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley publishing co. · leaf 135
BUTTERFLY T SECONDARYWELL P CHOKE X CAP JET H MAIN JET 0 COMPENSATOR I Fig. 51.—Sectional View of Zenith Compound Nozzle Compensating Carburetor. 136 Aviation Engines … Action of Zenith Carburetor 137 inference to suppose that as the speed of the motor in-creases, both the flow of air and of gasoline will increasein the same proportion. Unhappily, snch is not the case.There is a law of liquid bodies which states that the flowof gasoline from the jet increases…
Airplanes
