Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 213
e following extracts are repro-duced by permission. Crank-shaft, connecting rods andall other parts within the crank-case and cylinders arelubricated directly or indirectly by a force-feed oilingsystem. The cylinder walls and wrist pins are lubricatedby oil spray thrown from the lower end of… … 212 Hall-Scott Lubricating System 213 from connecting rod bearing directly upon the wrist pin.The oil is drawn from the strainer located at the lowestportion of the lower crank-case, forced around the mainintake manifold oil jacket. From here it is circulatedto the main distributing pipe located…
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
