Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 526
Fig. 233.—End View of Thomas-Morse 150 Horse-Power Aluminum CylinderAviation Motor Having Detachable Cylinder Heads. the pistons are also made of aluminum. This engine isactually lighter than the earlier model of less power.It weighs but 525 pounds, -with self-starter. The general Snet e en-Valve… … Fig. 234.—Side View of Thomas-Morse High Speed 150 Horse-PowerAviation Motor with Geared Down Propeller Drive. lines the reduction gear-case and the propeller shaftsupporting bearings. SIXTEEN-VALVE DUESENBERG ENGINE This engine is a four-cylinder, 4% x 7, 125 horse-power at 2,100 R. P. M. of the…
Airplanes
Internet Archive · Cornell University Library · Public Domain Mark 1.0. Free to use for anything.
