cylinders to the pair, instead ofsingly as in the previous case. The large pipe crossing atabout the center of the cylinders is the exhaust pipe (shownin front of the left pair), and the pipe shown under theexhaust is the water inlet pipe from the circulating pump. Itwill be seen from the… … Six Cylinder Rutenber Automobile Motor, with Cylinders Cast in Pairs. the oil shield (lower half) to be removed without disturbingthe adjustment of the bearings, when it becomes necessaryto inspect the internal mechanism. Large removable plates cover the top of the water jacketsso that it is a…
