Aviation engines, design - construction - operation and repair; a complete, practical treatise outlining clearly the elements of internal combustion engineering with special reference to the design, construction, operation and repair of airplane power plants; also the auxiliary engine systems, such as lubrication, carburetion, ignition and cooling. It includes complete instructions for engine repairing and systematic location of troubles, tool equipment and use of tools, also outlines the latest mechanical processes (1917)
Pagé, Victor Wilfred, 1885-1947 · New York, The Norman W. Henley Publishing Company · leaf 550
extent has cooled the oil inthe crank chamber and has itself been heated to assist Mercedes Engine Details 549 in the vaporization. The inlet pipes themselves are cop-per. All the passages between the venturi throat andthe inlet valve have been carefully finished and polished.The only abnormal… … Fig. 245.—Part Sectional View of 90 Horse-Power Mercedes Engine,Which is Typical of the Design of Larger Sizes. possesses two very real virtues in that it cuts down heightof the motor and the piston passes over the bottom deadcenter much more slowly than with a long rod. Other features of the…
Airplanes
